Apply most of the pressure during filing against or toward the point of the large green arrow. Use light downward pressure on the file to keep the cut straight and parallel. The precise cut you made in the EMT is positioned just above the yellow line. Lock it in place by lightly driving the wedge end of a straight screwdriver between the pulley or collar and the vise jaw where the green arrow appears in the graphic. The pulley or collar will be able to turn a little on the EMT. The other jaw will cover the same area at the opposite end of the EMT. Put the assembly in a vise so one of the jaws covers the yellow line. Normally, there will be a set screw and the keyway will align with it. Rotate the opening you cut until it is where the keyway should be. (Squeeze it evenly in a vise if too large, or pry the edges of the opening apart a little until the EMT fits the hole somewhat closely.) Insert the EMT in the pulley or collar shaft hole. That is fine as long as you can always know which is the cut precisely parallel to the side of the EMT.įit the EMT to the shaft hole by either compressing or expanding its diameter. This second cut may not be as precise as the first cut. Make a second cut to remove a piece from the EMT about a quarter of an inch wide. Mark the EMT to indicate the very straight cut and distinguish it from a second cut described in the next paragraph.

20 ykey way

Use a hacksaw or a Dremel tool with a cutter disc to make a cut that very precisely follows the line you made. Very carefully cut along the line as shown in the second graphic. Note the orange colored line in the first graphic.

20 ykey way

Bring a piece of wood up to the EMT and use a marker to make a line along the length of the EMT. A tubing cutter works very well, but a hacksaw will suffice.

20 ykey way

Anything done by hand with a file quickly wanders off of a desired straight line.Ĭut a piece of EMT close to the internal diameter of the shaft hole so it is just 1/16 to 1/8 inch longer than the pulley or collar is wide. The internal keyway cut inside the shaft hole must be parallel to the existing keyway on the motor shaft. ** An alternate method for cutting an internal keyway is to mount a cutter the size and shape of the desired keyway on a bar and manually crank the tool holder down the lathe bed so the cutter removes no more than 1/1000th inch per cut. I would have saved a lot of time and effort if only I had made the original keyway 1/8 inch deeper before enlarging the shaft hole. * As I began enlarging the shaft hole, I believed enough of the old keyway would remain that I could simply deepen it with a file, but enlarging the shaft hole removed the entire keyway. A short piece of electrical metallic tubing (EMT, or thinwall conduit).Expanding the diameter of the shaft hole was not difficult, but I needed to add an internal keyway.* I decided to file a keyway by hand because that fit the tools I have available, and I successfully did it once before on a smaller collar.** The shaft on the new motor is 7/8 inch in diameter. The shaft on the old motor was 3/4 inch in diameter.
